| MODEL |
C-320NC |
C-420NC |
C-520NC |
| Capaaity |
Round |
320 mm |
420 mm |
520 mm |
| Square |
320 mm |
420 mm |
520 mm |
| Rectangular (HxW) |
380 x 320 mm |
420 x 420 mm |
560 x 520 mm |
Saw
Blade |
Speed |
20-100 m/min. |
20-100 m/min. |
20-100 m/min. |
| Size (LxWxT) |
4240L x 34W x 1.1Tmm |
4770L x 41W x 1.3Tmm |
6040L x 54W x 1.6Tmm |
| Tension |
Hydraulic (Automatic blade breakage detection) |
Motor
Output |
Saw blade |
5 HP (3.7 KW) |
7.5 HP (5.6 KW) |
7.5 HP (5.6 KW) |
| Hydraulic |
1 HP (0.75 KW) |
2 HP (1.5 KW) |
2 HP (1.5 KW) |
| Coolant |
1/8 HP (0.1 KW) |
1/8 HP (0.1 KW) |
1/4 HP (0.19 KW) |
| Floor Space |
2010 x 2000 x 1900 mm |
2490 x 2360 x 1735 mm |
3175 x 2261 x 2261 mm | |
|
|
